BMS 4544

в наличност в наличност
BMS 4544

BMS 4544

4544 Specification

Throat diameter:1" (25.4 mm)
Nominal impendance:8 or 16 Ohm
Power capacity (AES):80 W
Peak Power:400 W
Sensitivity
CD Horn 90° x 75°, 1 W / 1 m:113 dB
Plane Wave Tube, 1 mW:117 dB
Maximal SPL (cont.):132 dB at 80 W
Frequency Range:500 - 20000 Hz
Recommended Crossover:1300 Hz
Voice Coil Diameter:1.75" (44.4 mm)
Magnet Material:Ferrite
Flux Density (Tesla):1.85
Voice Coil Material:Copper Clad Aluminum
Voice Coil Former:Kapton TM
Diaphragm Material:Polyester



4544 Mounting Information

Overall Diameter:mm110
Depth:mm47
Net Weight:kg1.53
 2 x M6 Holes,180° on 76.2 mm Diameter
отвори галерията на BMS 4544BMS 4544
отвори галерията на BMS 4544BMS 4544
отвори галерията на BMS 4544BMS 4544


в наличност в наличност
