Precision Sound M 6515

Model

M6515K

Nominal diameter

in.

6.5

Power handing capacity

W

100

Program power

W

200

Nominal impedance

Ohm

8

Sensitivity (1W/1m)

dB

96.6

Frequency range

Hz

150-7000

Voice coil diameter

in

1.5

Fs

Hz

140

Re

Ohm

6

Qms

9.5

Qes

0.32

Qts

0.31

Vas

L

3.0

Mms

gr

10.5

Cms

mm/N

0.12

BL

Tm

13.1

Xmax

mm

2.6

Overall diameter

mm

167

Bolt circle diameter

mm

166

Baffle cut-out diameter

mm

153

Overall depth

mm

82

Net weight

Kg

2
