OBERTON 10M150
не е наличен
OBERTON 10M150
Приложение: 10M150 съчетава високотемпературна алуминиева 51 мм звукова бобина; алуминиево шаси и феритна магнитна система с 134 мм магнит. Резултатът е 10” среднотонов високоговорител с добра чувствителност, подходящ за приложение като средночестотна част в трилентови тонколони, за вътрешно и външно озвучаване, както и за мидбас в компактни двулентови тонколони.
| Nominal Diameter Impedance Minimum Impedance Power Capacity AES ¹ Power Capacity ² Program Power ³ Sensitivity Frequency Range Voice Coil Diameter Voice Coil Material Voice Coil Former Voice Coil Winding Depth Magnet Gap Depth Cone Material Basket Magnet Flux Density | 10"/262mm 8 Ohm 5.25 Ohm 200 W 150 W 400 W (200-5000 Hz) 99 dB/W/m 75 - 6000 Hz 51 mm Aluminium Kapton™ 10 mm 7 mm Paper Die cast aluminium Ferrite 1.35 T |
1. AES standard. Power is calculated on rated minimum impedance. | |
| Resonance Frequency Mechanical Efficiency Factor (Qms) Electrical Efficiency Factor (Qes) Total Q (Qts) Equivalent Air Volume (Vas ) Diaphragm mass ind. airload (Mms) Voice Coil Resistance Re Effective Diagram Area (Sd) Peak Linear Displacement of Diaphragm (Xmax) Mechanical Compliance of Suspension (Cms) BL Product (BL) V.C. Inductance at 1 kHz (Le) | 74 Hz 8.89 0.45 0.43 25.9 Litres 25.54 Grams 5.15 Ohms 317.3 cm² +/- 3.25 mm 0.18 mm/N 11.62 T.m 0.88 mH |
| * Linear Mathematical Xmax is calculated as: (Hvc - Hg)/2 + Hg/4 where Hvc is the voice coil depth and Hg is the gap depth. | |
MOUNTING INFORMATION
| Overall Diameter Baffle Hole Diameter Number of Mounting Holes Bolt Circle Diameter Overall Depth Net Weight | 461 mm |
