PIONEER GM-D7400M

Maximum Output Power 1 x 400W (4Ω) or 1 x 800W (2Ω)

CEA 2006 Power (THD + N = 1%) 1 x 200W (20Hz - 240Hz/4Ω)
1 x 400W (50Hz / 2Ω)
54 dBA (ref: 1W into 4Ω)

Frequency response 10 - 240 Hz

Distortion < 0.3 %

S/N ratio > 80 dB

Bass Boost 50Hz, 0/6/12 dB

LPF 40 - 240 Hz (-12 dB/oct)

MOSFET output section (+) Yes

RCA terminals Yes (input)

Speaker Terminals Block-type

Input level control RCA (200mV - 6.5V)
SP (0.8V - 26V)
Switchable, LR independent

Max. current consumption (A/4Ω) 27 A

Chassis size (W x H x D) 225 x 56 x 200 mm

Unit weight 2.6 kg
